2722NT High Tensile Tyre Steel Wire For Tire Belt And Carcass , CE ISO Standard

Product Categories
HUBEI FUXING NEW MATERIAL TECHNOLOGY CO.,LTD
Contact Now

2722NT High Tensile Tyre Steel Wire For Tire Belt And Carcass , CE ISO Standard

Brand Name : FUXING

Model Number : 2+7x0.22 , 2722NT

Certification : ISO9001, CE, Lloyd's, ISO14001, OHSAS18001

Place of Origin : CHINA

MOQ : 1 TONS

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 15000 Tons per month

Delivery Time : 10-15days

Packaging Details : Pakcked in B40, B60 or B80 Steel Spool

Raw Material : 72A

HS Code : 73121000

Usage : Suitable for Radial Tire of Car and Truck

Standard : ASTM, BS, DIN, GB, JIS

Wire Gauge : 0.15-0.35mm

Surface treatment : Brass or copper coated

Lay Direction : Z or S type

Tension Grade : HT,NT,ST,PST,HE,HI,UT

Contact Now

Description:

radial tyre steel cord

radial tyre steel cord is also called hose wire,brass-plated steel wire,rubber tube wire,or brass rubber tube wire. Brass coated steel wire(hose wire) is manufactured according to BS, ASTM,EN,ISO or customers requirements.It is widely used as reinforcement layer of the rubber hose, and wrapped plastic hose in the form of braid or spirally wrapped(spiral hydraulic hoses). These high-pressure rubber hoses could sustain high pressure and high impact,and they can be used for machinery,aviation,ocean,oil drilling industry and some other special occasions. The surface of steel wire for hose reinforcement is plated a layer of uniform copper zinc alloy.

Features:

1. Combination of high strength and ductility, The wire has featured with better intensity and flexibility, and can be adhered to rubber better.

2. Consistency of physical properties

3. Uniform and appropriate surface finish, uniform winding and proper coil characteristics, strong grip of wire

We mainly produce hose reinforcement steel wire a wide range with the diameter of 0.2-2.5mm or as per customers requirements.

Performance Comparison

Performance index

3+8*0.35

HT

3*0.20+6*0.35

HT

3+9*0.22+0.15

HT

3*7*0.20

HE

3+9+15*0.22+

0.15NT

3+9+15*0.175+

0.15NT
Diameter (mm) 1.44±0.07 1.12±0.06 1.17±0.06 1.38±0.08 1.62±0.08 1.34±0.07
Linear density (g/m) 8.44±0.42 5.34±0.27 3.85±0.20 5.77±0.23 8.50±0.30 5.42±0.19
Mass of coating (g/kg) 3.60±0.50 3.65±1.00 3.87±1.00 4.30±0.90 3.90±1.00 4.90±1.00
Copper content(%) 63.5±2.50 63.5±2.5 63.5±2.50 63.5±2.50 63.5±2.5 63.5±2.50
Breaking force(N/line) 2975 1850 1380 1325 2700 1720
Residual torsion (T/6m) 0±0.3 0±0.2 0±0.3 0±0.4 0±0.3 0.25±3.0
Length of lay(mm,±5%) 10.0/20 10.0/18 6.3/12.5/3.5 3.9/6.3 6.3/12.5/18/3.5 5/10/16/3.5
Direction of lay S/S S/Z S/S/Z S/S S/S/Z/S s/s/z/s

WAREHOUSE PHOTO

2722NT High Tensile Tyre Steel Wire For Tire Belt And Carcass , CE ISO Standard
